SU University Researchers Develop Projection Lens Oscillation Process for 3D Printing Microlens Arrays

0
Image of 3D printed optical lens array by Luximprint used as header image for blog post on DLP 3D Printing lens arrays

Recently, researchers from the Singapore University of Technology and Design and Southern University of Science and Technology in Shenzhen, China, announced a breakthrough in the digital fabrication of microlens arrays using oscillation-assisted Digital Light Processing (DLP) 3D printing method.

To date, producing microlens arrays has proven to be difficult, according to the researchers. The current manufacturing technologies are time- consuming, have high process complexity, have a lack of fabrication flexibility, and face difficulty in consistency control.

Now, using a novel process of projection lens oscillation, the research teams have been successfully testing an approach for producing microlens arrays with proper surface smoothness using DLP 3D printing.

Micro Lens Arrays – A gentle Introduction

A microlens array (brief: MLA) consists of multiple micron-sized lenses with optical surface smoothness. An MLA has a supporting substrate with often individual lenses of about 10 micrometers on it. It is formed in a one-dimensional or two-dimensional direction. Today, MLA’s have become an important micro-optics device used in various compact imaging, sensing, and optical communication applications.

With the exception of Netherlands based Luximprint, a global leader in Additive Optics Fabrication, most traditional 3D printing methodologies have been unsuccessful in fabricating any optical component thus far, due to the presence of coarse surface roughness in 3D printed objects.

Projection Lens Oscillation

In this new approach, the computationally designed grayscale patterns are employed to realize microlens profiles upon one single UV exposure which removes the staircase effect existing in the traditional layer-by-layer 3D printing method, and the projection lens oscillation is applied to further eliminate the jagged surface formed due to the gaps between discrete pixels.

Optically smooth microlens array is fabricated by an oscillation assisted 3D printing method. Image via SUTD.
An optically smooth microlens array fabricated by a Projection Lens Oscillation process.
Image courtesy of SUTD.

Digital Light Processing for Details

DLP 3D printing is a process that uses a digital projector to cure photopolymer resin and produce 3D printed parts. It is often used for highly detailed 3D printing, and is considered a faster method than Stereolithography, a similar 3D printing process. Although DLP 3D printing offers great flexibility in the fabrication of microlens arrays with different sizes, geometries, and profiles, it has been unable to produce parts with optically smooth surfaces.

Oscillation DLP Printing: Ultrafast & Flexible Fabrication Method

To overcome this, the SUTD and SUSTech researchers suggested integrating DLP 3D printing with mechanical oscillation and grayscale UV exposure. Oscillation helps to remove the jagged surface formed by discrete pixels in a 3D printed part, whereas the grayscale UV exposure removes the staircase effect common to 3D printing, where layer marks are visible. The result is an ultrafast and flexible fabrication method for microlens arrays with optical surface smoothness.

3D Printing Smooth Microlenses

Although the research team has specifically adapted DLP for producing microlens arrays, various other 3D printing technologies are already suited towards its production.

A microlens array 3D printed on a Quantum X machine. Image via Nanoscribe.
A microlens array 3D printed on a Quantum X machine. Image courtesy of Nanoscribe.

For example, Germany-based Nanoscribe manufactures two-photon additive manufacturing systems that are capable of producing microlens arrays.

Also, for larger types of lens arrays, Dutch service provider for printed optics Luximprint offers optical quality lenses straight from the printer with zero need for post-processing.

Image or 3D printed microlenses by Luximprint
A gradient of 3D printed microlenses. Picture courtesy of Luximprint.

Economic Viability & Effectiveness

To prove the viability and effectiveness of the approach, the research team has conducted detailed morphology characterizations, including scanning electron microscopy and atomic force microscopy. Results suggested that the integration of projection lens oscillation with DLP 3D printing reduces surface roughness from 200 nm to about 1 nm.

Wrapping it all up, we may fairly conclude that, although the new DLP 3D process is still under investigation and not commercially available yet, the initial results are promising, and we can’t wait to see the first 3D printing devices entering the market.

NOTE: The SUTD + SUSTech Study, Ultrafast Three-Dimensional Printing of Optically Smooth Microlens Arrays by Oscillation-Assisted Digital Light Processing, was initially published in ACS Applied Materials & Interfaces.

Signify 3D Printing: Launch of Services for Tailor-made Luminaires in Professional and Consumer Applications

0
Image of a 3D printed decorative luminaire by Signify used as header for blogpost at 3DPrinting.Lighting

Signify, the world leader in lighting recently unveiled its facilities to 3D print light shades and luminaires in the Netherlands and plans to establish Signify 3D printing factories in the US, India and Indonesia. Over recent years, the company has perfected this highly flexible, more sustainable form of manufacturing, using a 100% recyclable polycarbonate material. It allows luminaires to be bespoke designed or tailored to customer’s exact needs and recycled at the end of their life, supporting a circular economy.

3D Printing for a Lower Carbon Footprint

Signify’s investment in 3D printing further illustrates the company’s commitment to better serving its customers while reducing their, and its own, carbon footprint. A typical manufactured luminaire (excl. electronics and optics) has a 47% lower carbon footprint than a conventionally manufactured metal luminaire. Nearly every component may be reused or recycled, supporting the concept of a circular economy.

“A typical manufactured luminaire has a 47% lower carbon footprint than a conventionally manufactured metal luminaire”.

Signify is the first lighting manufacturer to produce 3D printed luminaires on an industrial scale, reinforcing our position at the forefront of lighting and sustainable innovation. Printing luminaires provide a more flexible, fast and more environmentally friendly way to manufacture.

Fashion and food retailer Marks and Spencer (M&S) announced it is in the first phase of rolling out thousands of 3D printed luminaires across stores in the UK.

It is now possible to create new, or customize existing designs, that fulfill customer needs quickly without huge investments and long development cycles. Users can have their ideas brought to life in a matter of days rather than months and printing requires less energy.

Signify 3D Printing Facilities – Global Expansion

Signify already has a 3D printing facility at Maarheeze in the Netherlands. It aims to have up to 500 3D printers of different sizes with the ability to create luminaires up to 60 cm height and width. In January 2020, new Signify 3D printing facilities will be operational in Burlington, Massachusetts, US, serving both professional and consumer markets. Additional facilities in Noida, India and Jakarta, Indonesia will follow quickly after. LED lights will be integrated into the luminaires at all these sites.

Reduce carbon footprint and material waste – Signify’s contribution of its 3D printed
luminaires to its users sustainability goal. Infographic by Signify.

Lighting for a Circular Economy

3D printing has been around for a while, but these range of 3D printed luminaires are the first real retail lighting application that improves the sustainability of our stores and are extremely complementary to corporate sustainability strategies. The potential for the printed fittings is enormous, both from an energy and cost-efficiency perspective. They are printed on demand to fit perfectly without need for adjustment or cutting into our ceilings. Users can also return them to have them recycled and new designs printed, enabling us to be current and topical.

Albert Heijn, the Dutch supermarket chain, started using bespoke decorative pendants in its fresh food sections back in 2017.

Albert Heijn, the Dutch supermarket chain, started using bespoke decorative pendants to enhance the atmosphere in its fresh food sections in over 100 stores in the Netherlands in 2017. Luminaires were printed in the style of fruit. In the meantime, other designs were deployed in multiple stores, in sections such as frozen food and coffee areas. The supermarket is able to refresh the designs by simply returning the shades to Signify which shreds them and prints new designs.

Consumers can now online design, tailor and order decorative luminaires.

Online Tailor, Print and Deliver Fast Service for Consumers

Yesterday, Signify also announced the rollout across Europe of the world’s first online service to enable consumers to tailor decorative luminaires. Included in the range is a customizable Philips LED table lamp made from 24 recycled CDs.

In 2018, 79% of Signify’s sales comprised sustainable revenues. The company is committed to be carbon neutral in 2020 and was recently named Industry Leader in the Dow Jones Sustainability Index for the third year in a row.

Optographix by Luximprint to be launched at Trends in Lighting 2019 Bregenz

0
Header image for blogposta bout Luximprint Optographix launch at TIL 2019

Trends in Lighting, the international show for Architects, Lighting Designers, Planners and Investors, is running in parallel with the established LED professional Symposium and Expo in Bregenz, Austria, at the heart of the European Lighting Industry. Luximprint, Dutch service provider for additively fabricated custom optics, decided to use the event as a launching platform for one of its latest technology advancements: Optographix by Luximprint.

Optographix by Luximprint

In addition to its primary business of optically functional 3D printed optics, Luximprint offers now 3D printed optical graphics: Optographix. The novel solutions enable interior and lighting designers and anyone involved in branding and interior design the possibility to start working with the ‘medium of light’ in a different way.

‘Northern Lights’ is a stunning lighting installation by Dutch Creative Design Firm Luminous Concepts utilizing the power of 3D Printed Optics and Optographix. Image courtesy of Luminous Concepts.

Marco de Visser, Co-Founder of Luximprint explains: “Optographix offer the international design community new ways of engaging with light. By using novel 3D printing technologies, translucent media and optically clear or colored resins and combine them with day and artificial lighting, surfaces are brought to life and start to create compelling and stunning light effects“.

Trends in Lighting vs. LED professional Symposium

For Luximprint, both leading lighting events in Bregenz are of great relevance. This year, Luximprint will be presenting printed LED optics at the LED professional Symposium. An interactive lecture will teach an audience of industry professionals how ‘Additive Optics Design and Fabrication Pave the Path to Novel System Design and Lighting Applications’. Seen from a purely functional perspective, the messaging is most relevant to engineers and designers of functional lighting systems.

The TiL 2019 program, at the other hand, explores a new horizon for lighting. The show has, for the third year in a row, created an outstanding event program, dedicated to bridging the gap between architecture, application, design and technologies.

‘Butterfly’ by Luminous Concepts is an interactive lighting installation in progress utilizing Luximprint Optographix Technology. Image courtesy of Luminous Concepts.

Optographix, which are considered as a ‘first-class lighting novelty’ are basically produced with the same printing process as printed optics. The optical translucency of the structures, critical for creating optically functional textures and typography, is created by applying the same optical resin formula in the printing and combining it with unique graphical 3D design methods. It is a perfect fit with the TIL 2019 visitor profile.

De Visser continues: “Optographix are a great new tool for brand enhancement and artistry, as they open up doors to applications and design spaces that were not accessible before”. When considering light as a medium rather than a static light source, suddenly, new ways of designing with light become within the reach”.

Lightly Technologies and Physionary

During the exhibition, Luximprint will be flanked by two more interesting lighting start-ups: Lighting Technologies, inventor of the revolutionary thin and powerful LED panels and Physionary, the Dutch design collective behind the groundbreaking Faceted Lens Technology.

Hikari SQ – Building Blocks for Lighting and Fixture Design

Lightly’s Hikari SQ LED panels at the one hand, go very well together with Luximprint Optographix. The powerful yet smooth light output are excellently suited as backlighting for Optographix. The fully controllable, ultra-thin and easy-to-integrate panels are a preferred choice by todays designer community.

Image of Lightly Hikari SQ display with embedded optographix. Image by Gavriilux.
Luximprint 3D Printed Optographix embedded in a display of Lightly Technologies.
Image by Gavriilux – www.gavriilux.com

Faceted Lenses: Light Where Needed

Physionary Design Software, on the other hand, is of great interest when it’s been used in the combination with Luximprint Additive Optics Fabrication technology. Where optical 3D printing breaks down the barriers in traditional lens manufacture, such as long lead times, tooling and inventory, Physionary software does so for the optics design part of the process.
The combination of both novel technologies is extremely powerful as it is now possible to create custom optics for any particular project case in a matter of days.

The Fresnel Sunflower Optic is an example of Faceted Lens Specialty designed by Physionary and printed by Luximprint. Image courtesy of Luximprint.

We will be following the further path of those interesting lighting start-ups with great interest, and keep you posted in case of new breakthroughs!

The powerful decorative and functional ‘start-up collective’ can be visited from September 24th-26th, 2019 in the Bregenzer Festpielhaus at booth #S3 – #S5 and #S7.

3D Printed Heat Sinks Display Higher Efficiency

0
_Header image for blogpost about 3D printed heat sinks by 3DPrinting.lighting

Heat sinks are a crucial part of lighting devices, dispersing the temperatures of the LED chip produced during operation. Light fixtures would simply overheat without having them. Improving heat sinks can have major benefits, for example for the airflow and thermal heat dispatching. To this end, teams of university researchers and engineers from various equipment providers have applied novel 3D printing technologies to demonstrate novel designs that can give heat sinks better efficiency for lighting applications. It comes as no surprise, that 3D printing technology significantly contributes to the development of making better, lighter and smarter heat sinks.

3D Printed Heat Sinks for Lighting

For many manufacturers of lighting equipment, natural convection of air-flows remains the preferred method for cooling the electronic components of a given light fixture. This method is cheap, simple to maintain and produces no noise or electromagnetic interference.

Natural convection, however, is limited in its scope, with medium to high power outputs tending to overwhelm the simple cooling system. Advanced 3D printing technology opens up doors to designs that could help significantly improve the efficiency of cooling bodies.

Some examples of newly invented cooling bodies by Plunkett Associates.

Heat-sinks help to guarantee a long service life of a light fixture and prevent it from early failure. Made from high thermal conductivity material such as aluminum or copper, these essential parts conduct heat from the electronic component towards the extremes of their own large surface areas. When the heat reaches these extremes, it can be convected to the air flowing overhead.

3D Printed Heat sinks: Lighter – Smaller – Better

Recently, researchers in the US, along with other European counterparts, have shown that 3D printed heatsinks could be lighter, smaller or better than conventional heatsinks. This conclusion comes from two linked projects at Oak Ridge National Laboratory and the University of Tennessee in Knoxville.

One proves that 3D printed aluminum heat sinks can at least equal and sometimes supersede the thermal conductivity of standard heatsink aluminum. The second has developed genetic algorithms that make use of the freedom of shape available from 3D printing to design heatsinks that fit in the same space as their conventional cousins but work better.

3D printed heatsink. Image showing a false-colour rendering of a heatsink designed to cool a module dissipating 2kW. Image property of ORNL

3D Printing Heatsinks – Pros & Cons

Now, with 3D printing capable of making heatsinks just as good as existing heatsinks the same shape, we may ask ourselves what benefits are available using the arbitrary shapes possible with 3D printing, and how these arbitrary shapes might be designed? Here are some insights into the benefits and challenges of the manufacturing process, as well as some practical designer tips.

Like any technology, 3D printing of metals has its advantages and disadvantages. The trick is to know both when it is appropriate to use it and find the ideal applications for the process. For example, metal printing is a good option for creating complex parts that need to be strong and lightweight. The parts are also fully dense and can include precision internal features that cannot be created using traditional machining. Printing is additive, so it generates minimal waste.

Another benefit of 3D metal printing has to do with its reliability. Although it may take a few attempts to find the best parameters, design, and orientation for building a part, once discovered, the process is tremendously consistent. It will result in the same part every time, build after build. Although this may be assumed as a given for any manufacturing process, the predictability and efficiency of metal printing should never be overlooked.

The tradeoff to 3D metal printing’s benefits is that speed and cost cannot be driving factors for those who want to pursue this technology. This is why aerospace and automotive industries have been the most committed early adopters of the technology, rather than the more conventional and highly-cost oriented lighting industry. The lightweight, strong designs translate well to their applications.

Aluminum is an excellent thermal conductor, so it was used to 3D print these intricate, one-piece heat sinks for lighting applications.

Build times for 3D metal printing are longer compared to those for plastic 3D printing. It typically requires several builds to fine-tune a part’s design for mass production through 3D metal printing.

Before committing to designing parts for metal printing, designers should consider the material that is preferred for the part. Although there are a lot of materials people claim can be used for 3D printing, there is a very limited number of metals that can be printed on the market. It takes years of research and effort to develop the process parameters for specified materials in certain machines. This is a tricky aspect of the technology.

3D Printing Materials and Finishes

Some of the most common and reliable metals for 3D printing include stainless steel, aluminum, titanium, cobalt chrome and Inconel alloy. Choosing the best material is vital for ensuring parts will perform as needed.

Another design aspect to consider before going with choosing 3D metal printing is the desired surface finish. The surface finish of 3D printed part is poor due to it being built layer by layer. It takes post-machining on printed parts to get aesthetically pleasing surface finishes. This can be done using CNC machining or manual surface grinding, sanding, or polishing.

It may seem obvious, but size is another limed parameter. Parts cannot be larger than the machine’s build platform, which varies from printer to printer. Although there is no standard Build-platform size, the most common dimensions are around 250 × 250 × 300 mm, or smaller.

Heat sinks for LED light sources:

a) Industrial design solutions; b) Topology-optimized LED heat sinks for vertical, and horizontal orientations with 1/2 and 1/8 symmetries; c) 3D printed topology-optimized design with additional support; post-processed design with removed support; and simplified interpretation manufactured by traditional techniques.

Source: Experimental validation of additively manufactured optimized shapes for passive cooling , Research Gate.

Designing parts for Metal Printing

Generally, there is a fair amount of trial and error that goes into perfecting a design. However, there are some common design pitfalls that can be avoided to streamline the process. It’s important for designers to have the process in mind when creating CAD models. Different 3D metal printers have different limitations due to the laser spot size and melt pool. Despite this, there are some general guidelines that should be followed when designing parts for metal printing:

Wall thicknesses
Walls that are too thin will begin to collapse under their own weight. Walls should be no thinner than 0.5 mm.

Hollows and Gaps
The limitations for gaps and holes may vary widely based on the printer being used, the metals being used, and part geometry. The general rule of thumb is to not design a gap or hole under 0.5 mm. Smaller gaps run the risk of the sides merging together and filling the empty space. On the other hand, supports need to be added for holes greater than 10mm.

Overhangs
0.5 mm is the maximum length that should be used for an overhang, and all downward facing structures need to be designed to a chamfer (more than a 45-deg. angle to the horizontal), with a concave or convex shape so the part can support itself. Support structures need to be included in the part’s design to exceed these guidelines.

Support Materials
Supports are needed for two reasons. The first is to hold parts to the substrate plate. The second is for heat dissipation. Any areas below 45 deg. from horizontal need support to be added. This applies to most of the metals.

Part orientation
Unlike other manufacturing processes, 3D printing creates parts with different mechanical properties in different build directions. In the X and Y directions, for example, parts have higher tensile strength than they do in the Z direction. Hence, part orientation needs to be considered prior to printing. This is especially true if parts are for mechanical/structural purposes where a certain area will sustain some degree of pressure and stress.

There is also an aesthetic element to part orientation. Downfacing surface areas of printed parts will have a poorer surface finish compared to the top-facing surfaces. If certain areas of a part need better surface finishes, it should be taken into consideration during part orientation. For complex parts, it is important that part orientation is such that if there are supports that may affect part function, they can be removed.

Image of various 3D printed heat sinks.
Heat sinks with highly complicated textures created by using 3D Metal Printing.

Trends in Metal Printing

In the near future, hybrid additive/subtractive machines will find their niche. It is not uncommon to find metal printing and CNC machining as part of a single production line. CNC machining may be needed to remove supports added to make a printed metal part. With a plastic printed object, supports can sometimes be manually removed simply by snapping them off. This is not the case with metal printing where removing supports takes a significant amount of time and effort. Once supports are removed, surface work (a time-consuming process) may be required as well. Combining these processes in one machine could be very beneficial.

3D Printed Heat Sinks – Future Outlook

Although 3D metal printing is not as easy as 3D plastic printing, the process of perfecting a design is worth it due to the higher engineering standard of the process. Although combined additive and subtractive machines will grow the market, traditional 3D metal printers will as well. There may seem to be a lot of limitations when it comes to metal printing, the industry fully expects the technology to go mainstream. It can be used to build parts that would be impossible by any other process due to complexity.

The key to metal printing’s growth and adoption will depend on widespread knowledge of designing parts for 3D printing. Some responsibility will fall on manufacturers to find avenues to share their knowledge with designers and one another.

The generally longer build times will begin to dissolve as new generations of metal printers come to market and the technology is perfected. Time will also lead to a wider range of metal powders to use for the process. Overall, 3D metal printing will likely prove to be the greatest development in low-volume manufacturing of metal parts over the next 50 years.

Conclusions

From what we at 3DPrinting.Lighting have read, heard and seen, we may conclude that the many optimization efforts to date result in significant material savings and design improvements of passive LED coolers. The possibility to account for several physical fields and their complex interaction, provides close to optimal utilization of the heat sink material and moves performance bounds close to the limit.

For such broadly applied and well-studied devices, reduction upto 20% in material utilization in unison with a 21-23% temperature decrease is still achievable, fully demonstrating the potential of 3D printed heat sinks. Optimized designs can be produced using 3D printing techniques or can be simplified further making them suitable for traditional manufacturing with only a small loss of performance. Higher computational efforts are required to account for additional physical effects and practical constraints.

The benefits in material savings and decreased temperature justify a certain cost increase in the design phase. Extensions to more complex multi-physical interactions including heat transfer in turbulent flows, magnetic refrigeration or cooling are still in their infancy, but cater for further future improvements in energy consumption of thermal and other systems!

This post was kindly inspired by Electronics Weekly, MachineDesign.com and the research study Optimized Shapes for passive cooling by researchers of the Universities of Denmark and Manchester.
